Insulation Lacing Hooks Without Pin (2 Holes)

Our lacing hooks (without pin) are trusted fasteners for fabricating removable insulation jackets and blankets. These blankets are typically built with three layers—a coated glass fabric facing, a liner, and a fiber felt core. The hook works with a lacing wire that penetrates all layers and connects to a two-hole locking washer on the reverse side. Tensioning and tying the wire completes the assembly, ensuring a snug, secure fit.
分类：
Insulation Lacing Hooks Without Pin (2 Holes)
Diameter of lacing hooks 25mm
Diameter of 2 holes 5mm
Thickness of lacing hooks 1mm
Thickness of 2 holes washer 0.4mm
Material Stainless steel, Galvanized steel
Package According to your needs.
Remark Special request could be customized.

2 hole lacing top



Key Features

  • Secure tensioned hold with lacing wire and 2-hole locking washers.

  • Designed for removable and reusable insulation jackets.

  • Available in 304 SS, 316 SS, and galvanized steel.

  • Corrosion-resistant and built for long service life.

  • 25 mm flat base with two 5 mm holes for easy wire threading.

Application
Ideal for removable insulation jackets on valves, flanges, turbines, pumps, and exhaust systems. Widely used in power generation, petrochemical, HVAC, marine, and industrial equipment insulation. Compatible with glass fabric, fiberglass, mineral wool, and ceramic fiber blankets.
